View In:   ArcGIS Online Map Viewer

Name: Slopes above 20 Degrees

Display Field: Id

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: This data is a polygon representation of the reclassified slope raster derived from the bareearth mosaic of DOGAMI"s mosaic raster and the 2023 OLC Jackson County BE (as reference below), reprojected and transformed to OCRS NAD 83 2011(2010). To reduce the many small areas, the minimum polygon size was set at 2,000 square feet, collapsing any area smaller.The Slope Raster reclass parameters:20- above percent slopeProduct: This GIS dataset contains Bare Earth (BE) raster models depicting lidar-derived elevation data for the 2023 OLC Jackson County Lidar project area. Raster models were delivered by AOI mosaic in addition to the 3000ft tiles. Dataset Description: The 2023 OLC Jackson County Lidar project area encompasses 506,952 acres; and is located in Jackson County, Oregon. This project called for the planning, acquisition, processing, and production of derivative products of lidar data and was to be collected at a nominal pulse spacing (NPS) of 8 ppsm - 0.35 meters. Project specifications are based on the U.S. Geological Survey National Geospatial Program Lidar Base Specification, Version 2022 rev. A. The native projection is Oregon Lambert Conic Conformal, units are in International feet. The native horizontal datum is NAD83(2011); the native vertical datum is NAVD88; Geoid 18. Bare earth DEMs were derived from the classified lidar data and delivered within a 3000 ft x 3000 ft tiling schema. Ground Conditions: Lidar was collected between November 14th, 2002 - November 22nd, 2002 and June 28th, 2023 - June 30th, 2023 while no snow was on the ground and the area was free of cloud cover.Using Countwide LiDAR Mosaic, Slope was extracted from the bare earth digital elevation model. Slope was then reclassified to certain slopes. The Slopes above 20 percent grade data was extracted from the Slope Reclassified raster. Then City Limits and Public properties removed. Finally, the data went through a Simplify Polygon with a minimum area of 2000 square feet.

Service Item Id: d09d5450710f434e911021e9928a44ab

Copyright Text:

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: 191762.0821580924
YMin: 92386.79287663102
XMax: 447783.7471097708
YMax: 456054.59899908304
Spatial Reference: 6827  (6827)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [115, 38, 0, 255]
Outline:
Style: esriSLSSolid
Color: [110, 110, 110, 255]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: true
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: false
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field:

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )
• Id ( type: esriFieldTypeInteger, alias: Id, editable: true, nullable: true, defaultValue: null, modelName: Id )
• gridcode ( type: esriFieldTypeInteger, alias: gridcode, editable: true, nullable: true, defaultValue: null, modelName: gridcode )
• InPoly_FID ( type: esriFieldTypeInteger, alias: InPoly_FID, editable: true, nullable: true, defaultValue: null, modelName: InPoly_FID )
• MaxSimpTol ( type: esriFieldTypeDouble, alias: MaxSimpTol, editable: true, nullable: true, defaultValue: null, modelName: MaxSimpTol )
• MinSimpTol ( type: esriFieldTypeDouble, alias: MinSimpTol, editable: true, nullable: true, defaultValue: null, modelName: MinSimpTol )
• Shape__Area ( type: esriFieldTypeDouble, alias: Shape.STArea(), editable: false, required: true, nullable: true, defaultValue: null, modelName: Shape.STArea() )
• Shape__Length ( type: esriFieldTypeDouble, alias: Shape.STLength(), editable: false, required: true, nullable: true, defaultValue: null, modelName: Shape.STLength() )

Templates:

• Name: Slopes above 20 Degrees
  Description:
  Prototype:
  MinSimpTol: null
  Id: null
  gridcode: null
  InPoly_FID: null
  MaxSimpTol: null

  Drawing Tool: esriFeatureEditToolPolygon

Capabilities: Query

Sync Can Return Changes: false

Is Data Versioned: false

Supports Rollback On Failure: true

Supports ApplyEdits With Global Ids: false

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true

Child Resources:   Field Groups   Contingent Values

Supported Operations:   Query   Query Analytic   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata   Update Metadata
