Name: Jackson County Streams

Display Field: StreamName

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: Jackson County Streams layer is derived from Oregon Department of Forestry Hydrography Flowline (May 09, 2025 update) data, which is developed from best available digital elevation models from 2m LiDAR and the 10m National Elevation Dataset. For more information regarding the ODF dataset please see ODF"s ArcGIS Hub - Hydrography Flow Line | ODF ArcGIS Hub. The statewide data is reduced to the Jackson County boundary and is edited, both in geometry and attributes, to meet the County’s needs.The Jackson County Planning Class (JCclass) field is added to the Streams layer. This field reflects Jackson County’s Stream Classifications, as defined in Chapter 13 of the 2004 Land Development Ordinance and in chapter 16 of the 1989 Jackson County Comprehensive Plan. The Stream Classifications are aligned with Statewide Planning Goal 5 and with OAR 660-023-0090. Furthermore, the Stream Classifications are not related to a typical hydrologic class or type, but exclusively the land-use planning designation.Class 1 attributes (JCclass field) are applied to the new Streams flowlines to match the previously approved Class1 flowlines’ geometry. The archived Streams and Irrigation Canals data can be found here - CountyStreams - OverviewClass 2 attributes are applied to the new Streams flowlines using a series of select-by-location processes, involving Class 2 flowlines from Original Streams & Irrigation Canals and USGS 3DHP flowlines, then afterwards a careful and arduous systematic review of Class 2 flowlines results. During the review, geometry and attribute edits were made to better reflect the location and Class 2 designation.Perfect geometry and attributes are unlikely given the complexity of the situation however significant and continuous efforts are made to review and improve the flowlines and attributes with best available GIS data and tools. For step-by-step processing of the Streams flowlines, please contact Jackson County GIS.

Service Item Id: 0eddb66b51e4440795fdd93a562d7542

Copyright Text: Oregon Department of Forestry USGS 3DHP Jackson County GIS Jakcon County Development Services

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 188584.8267716542
YMin: 88374.53871390969
XMax: 451535.3225065619
YMax: 458069.63812336326
Spatial Reference: 6827  (6827)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: JCClass
Field 2: StructureType
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: 1,<Null>
  Label: Class 1 Streams
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [0, 77, 168, 255]
  Width: 2
• Value: 2,<Null>
  Label: Class 2 Streams
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [0, 112, 255, 255]
  Width: 1
• Value: 2,Underground
  Label: Class 2 Underground Streams
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [0, 112, 255, 255]
  Width: 1
• Value: <Null>,<Null>
  Label: other flowlines
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [130, 130, 130, 255]
  Width: 0
• Value: <Null>,Underground
  Label: other underground flowlines
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [130, 130, 130, 255]
  Width: 0
Transparency: 0
Labeling Info:
Label Placement: esriServerLinePlacementAboveAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 132, 168, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: AvenirNext LT Pro Medium
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 150000.0
Max. Scale: 0.0
Label Placement: esriServerLinePlacementAboveAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 132, 168, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 9
Font Family: AvenirNext LT Pro Regular
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 50000.0
Max. Scale: 0.0
Label Placement: esriServerLinePlacementAboveAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 77, 168, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: AvenirNext LT Pro Medium
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 375000.0
Max. Scale: 150000.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: true

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• JCClass ( type: esriFieldTypeSmallInteger, alias: Jackson County Planning Class )
• StreamName ( type: esriFieldTypeString, alias: Stream Name, length: 50 )
• FishPresence ( type: esriFieldTypeSmallInteger, alias: Fish Presence , Coded Values: [1: Fish] , [2: Non-Fish] , [9999: NA - No Channel] )
• FishVerificationMethod ( type: esriFieldTypeSmallInteger, alias: Fish Verification Method , Coded Values: [1: Assumed] , [2: Dphys] , [3: Survey Verified] , ...2 more... )
• FishVerificationSource ( type: esriFieldTypeSmallInteger, alias: Fish Verification Source , Coded Values: [1: ODF] , [2: ODFW] , [3: Landowner] , ...7 more... )
• FishPresenceSurveyDate ( type: esriFieldTypeDate, alias: Fish Presence Survey Date, length: 8, precision: 1 )
• FishPresenceSurveyID ( type: esriFieldTypeString, alias: Fish Presence Survey ID, length: 50 )
• FishPresenceModDate ( type: esriFieldTypeDate, alias: Fish Presence Modification Date, length: 8, precision: 1 )
• Barrier ( type: esriFieldTypeSmallInteger, alias: Fish Barrier , Coded Values: [1: Culvert] , [3: Natural] , [4: None] , ...2 more... )
• BarrierYear ( type: esriFieldTypeSmallInteger, alias: Fish Barrier Year , Coded Values: [1992: 1992] , [1993: 1993] , [1994: 1994] , ...34 more... )
• BarrierModDate ( type: esriFieldTypeDate, alias: Fish Barrier Modification Date, length: 8, precision: 1 )
• BarrierSurveyID ( type: esriFieldTypeString, alias: Fish Barrier Survey ID, length: 50 )
• FPAStreamSize ( type: esriFieldTypeSmallInteger, alias: FPA Stream Size , Coded Values: [1: Small] , [2: Medium] , [3: Large] , ...1 more... )
• FPAStreamSizeSource ( type: esriFieldTypeSmallInteger, alias: FPA Stream Size Source , Coded Values: [1: Field] , [2: DEM] , [3: Calculated] , ...1 more... )
• StreamWaterUse ( type: esriFieldTypeSmallInteger, alias: Stream Water Use , Coded Values: [1: Community] , [2: Domestic] , [9999: Unknown] , ...1 more... )
• ChannelType ( type: esriFieldTypeSmallInteger, alias: Channel Type , Coded Values: [1: Channel] , [2: No Channel] , [3: Water Development] )
• StreamPermanence ( type: esriFieldTypeSmallInteger, alias: Stream Permanence , Coded Values: [1: Perennial] , [2: Seasonal] , [9999: NA - No Channel] )
• StreamPermanenceModDate ( type: esriFieldTypeDate, alias: Stream Permanence Modification Date, length: 8, precision: 1 )
• StreamPermanenceSource ( type: esriFieldTypeSmallInteger, alias: Stream Permanence Source , Coded Values: [1: NHD] , [2: Survey] , [3: Model] )
• StreamPermanenceSurveyID ( type: esriFieldTypeString, alias: Stream Permanence Survey ID, length: 50 )
• StreamPermanenceSurveyDate ( type: esriFieldTypeDate, alias: Stream Permanence Survey Date, length: 8, precision: 1 )
• StreamTermination ( type: esriFieldTypeSmallInteger, alias: Stream Termination , Coded Values: [1: Terminal] , [2: Lateral] , [9999: None] )
• DistanceToFish ( type: esriFieldTypeDouble, alias: Distance to Fish Presence )
• DistanceToSSBT ( type: esriFieldTypeDouble, alias: Distance to SSBT )
• SSBTStatus ( type: esriFieldTypeSmallInteger, alias: SSBT Status , Coded Values: [1: SSBT-CPO] , [2: SSBT-OBS] , [3: No SSBT] , ...1 more... )
• SpeciesEdit ( type: esriFieldTypeSmallInteger, alias: Species Edit , Coded Values: [1: Fish Presence] , [2: SSBT Status] , [3: Both Fish Presence and SSBT Status] , ...1 more... )
• GeometrySource ( type: esriFieldTypeSmallInteger, alias: Geometry Source , Coded Values: [1: Lidar] , [2: NED 10M] )
• DEMSource ( type: esriFieldTypeString, alias: DEM Source, length: 254 )
• HUC8 ( type: esriFieldTypeString, alias: HUC8 Watershed Code, length: 8 )
• HUC8Name ( type: esriFieldTypeString, alias: HUC8 Watershed Name, length: 120 )
• StructureType ( type: esriFieldTypeString, alias: Structure Type, length: 255 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
